Precision air conditioner to control temperature and humidity both
The constant temperature and humidity unit is used for indoor air conditioning under various environmental conditions and has many functions such as cooling, dehumidification, heating, humidification and ventilation. The temperature control range is 18~30℃, with control accuracy of ±1℃. The relative humidity is set at 50-70%, with control accuracy of 5%. This product is indispensable auxiliary equipment for scientific research, national defense, industry, agriculture, commercial services and other departments.
It is suitable for places with high requirements of temperature and humidity, such as electronic computer rooms, radio or electronic equipment control rooms, laboratories of scientific research organizations, precision instruments, precision machining workshops, color printing workshops, textile inspection rooms, and precision metering rooms.
Product features
-Highly sensitive temperature measuring control panel -CAREL temperature and humidity sensor
-Accurate measurement and control technology, adjustable temperature range: 18℃ ~ 30 ℃
-Humidity control accuracy: ±5%RH, temperature control accuracy: ±1℃
-More reliable performance and more flexible functions -Uniform humidification, large humidifying capacity and automatic detection of water shortage
Touch HD LCD panel;Support Modbus RS485 Protocol. CAREL Temperature and humidity sensor;Accurate measurement technology. Efficient electrode humidifying:
Clean, without impurities.
Performance Model
JHMS-03B
JHMS-05B
JHMS-09B
JHMS-12B
JHMS-20B
JHMS-30B
JHMS-40B
JHMS-50B
JHMS-60B
Usage area
㎡、height 3m
10-15
15-25
25-35
35-55
60-80
80-120
130-160
160-200
200-240
Overall performance
Cooling capacity
kw
3.5
5
9.2
12
20
30
40
50
60
Heating capacity
kw
2
3.5
5
7
12
18
21
28
32
Air volume
m3/h
550
1000
2200
3000
4200
5500
8000
10000
12000
External static pressure
Pa
50
50
100
150
100
150
200
300
300
Unit noise
dB
58
58
60
62
62
65
68
70
72
Controller
PLC intelligent touch screen
Temperature control range
Temperature control range: 18-30°C, accuracy: ±1°C
Humidity control range
Temperature control range: 50~70%, accuracy: ±5%RH (or customized to be ±2%RH)
Power
220V-50Hz
380V-50HZ-3PH
22
35
43
53
65
Total unit capacity
kw
5
7.2
11.2
15.5
22
35
43
53
65
Cooling system
Compressor
Type
Rotor
Scroll
Power
1*1.125
1*1.5
1*2.3
1*3.75
1*6
2*7.5
2*12
2*15
2*18
Refrigerant
Type
R22/R410a, Thermal Expansion Valve
Auxiliary electric heating
Type
Electric heating
Power
kw
2
3.5
5
7
12
18
21
28
32
Humidifier
Type
Electrode/Electric heating
Humidifying capacity
kg/h
2
2
4
4
4
8
8
15
15
Power
kw
1.5
1.5
3
3
3
6
6
11.25
11.25
Indoor unit
Size/L*W*H
mm
800*480*1825
800*480*1825
960*580*2025
960*580*2025
1222*742*1885
1502*952*1975
1652*952*1985
1652*952*2083
1820*952*2185
Weight
kg
170
175
260
280
340
390
430
490
520
Outdoor unit
Size(L*W*H)
mm
857*440*616
857*440*616
1093*456*813
1193*456*963
788*788*925
1193*456*963
788*788*925
888*838*1085
888*838*1085
Weight
kg
53
60
60
75
90
75*2
90*2
115*2
115*2
Copper pipe size/High-Low
mm
9.52/12.7
9.52/12.7
9.52/12.7
9.52/12.7
16/19
9.52*2/12.7*2
16*2/19*2
19*2/22*2
19*2/22*2
